26 Revolt X Advanced Pro 0
Product Details
Washboard descents, sketchy dirt, gravel and rocks of all shapes and sizes. You never know what you’ll get on a gravel ride. This composite gravel machine has front suspension and engineered compliance to help you float through it all with speed and control.
Key Performance Factors
Smooth control
Composite frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster on rugged gravel and dirt.
Tuned compliance
Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.
Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tires up to 53mm. You can choose the included dropper/suspension seatpost for added capabilities, or switch to a 30.9mm round seatpost.
Specifications
|
Sizes |
XS, S, M, M/L, L, XL |
|
Colours |
Kelp Forest/Charcoal/Chrome |
|
Frame |
Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout |
|
Fork |
Fox 32 Float TC Performance Elite, 40mm, Fit 4 damper12x100mm thru-axle |
|
Shock |
N/A |
|
Handlebar |
Giant Contact SL XR D-Fuse, 31.8mm XS:44cm, S:44cm, M:46cm, M/L:46cm, L:48cm, XL:48cm |
|
Grips |
Stratus Lite 3.0 |
|
Stem |
Giant Contact, 8-degree XS:50mm, S:50mm, M:60mm, M/L:70mm, L:70mm, XL:80mm |
|
Seatpost |
Post Moderne, dropper, 30.9mm with 30mm of suspension XS:365mm / 75mm drop S:415mm / 100mm drop |
|
Saddle |
Giant Approach SL |
|
Pedals |
N/A |
|
Shifters |
SRAM Force eTap AXS, 1x12 |
|
Front Derailleur |
N/A |
|
Rear Derailleur |
SRAM X01 Eagle AXS |
|
Brakes |
SRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]160mm |
|
Brake Levers |
SRAM Force eTap AXS hydraulic |
|
Cassette |
SRAM XG-1295, 12-speed, 10x52 |
|
Chain |
SRAM X01 Eagle |
|
Crankset |
SRAM FORCE 1 Wide, DUB 1X 40T XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
|
Bottom Bracket |
SRAM DUB, press fit |
|
Rims |
Giant CXR X1 WheelSystem, [F] 25.8mm, [R] 25.8mm |
|
Hubs |
[F] Giant CXR X alloy, CenterLock, 12mm thru-axle, [R] Giant CXR X alloy, 60t ratchet driver, CenterLock, 12mm thru-axle |
|
Spokes |
Sapim Laser |
|
Tires |
Maxxis Rambler, 700x50c, tubeless prepared |
|
Extras |
tubeless prepared, 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position |
